NP-ONE STAR
Cartoner with a rate of 200/250 capsules/minute.
Packaging up to 1 height
Star Mosaic Presentation
Up to 1 height
Star Mosaic
![NP ONE STAR](https://www.imasdsl.com/wp-content/uploads/2023/10/NP-ONE-STAR-1.jpg)
NP-ONE STAR
Our most versatile cartoner: it works with cases up to 4 heights, in star mosaic and a rate of 200/250 cap/min.
![ONE-2](https://www.imasdsl.com/wp-content/uploads/2023/10/ONE-2.png)
Type of capsules
![](/wp-content/uploads/2023/10/NP.jpg)
NESPRESSO
![](/wp-content/uploads/2023/10/TU-CAPSULA.jpg)
YOUR CAPSULE
Models
It contains the main capsule models on the market, adapting to specific formats and sizes.
![](/wp-content/uploads/2023/10/NP.jpg)
NESPRESSO
![](/wp-content/uploads/2023/10/TU-CAPSULA.jpg)
YOUR CAPSULE
![](/wp-content/uploads/2023/10/ALUMINIO.jpg)
ALUMINIUM
![](/wp-content/uploads/2023/10/PLASTICO.jpg)
PLASTIC
![](/wp-content/uploads/2023/10/COMPOSTABLE.jpg)
COMPOSTABLE
Materials
A machine for three types of capsules. Boxes that seek maximum protection, resistance and product presentation.
![](/wp-content/uploads/2023/10/ALUMINIO.jpg)
ALUMINIUM
![](/wp-content/uploads/2023/10/PLASTICO.jpg)
PLASTIC
![](/wp-content/uploads/2023/10/COMPOSTABLE.jpg)
COMPOSTABLE
Star Mosaic
Great protection and security for the capsule and coffee with an attractive and comfortable presentation.
![MOSAICO ESTRELLA](https://www.imasdsl.com/wp-content/uploads/2023/10/MOSAICO-ESTRELLA.png)
CHARACTERISTICS
Cases
![NP ONE STAR_Tipo A](https://www.imasdsl.com/wp-content/uploads/2023/10/NP-ONE-STAR_Tipo-A-2.jpg)
Reduces glue spots without compromising case integrity.
![NP ONE STAR_Tipo B](https://www.imasdsl.com/wp-content/uploads/2023/10/NP-ONE-STAR_Tipo-B-1.jpg)
An airtight design that guarantees maximum product safety.
![NP ONE STAR_Tipo C](https://www.imasdsl.com/wp-content/uploads/2023/10/NP-ONE-STAR_Tipo-C-2.jpg)
An agile opening and closing system with a premium design.
Optional
Choose the optional ones that best suit your needs:
Mesh separator
![](https://www.imasdsl.com/wp-content/uploads/2023/10/Separador-Mallado.jpg)
The mesh separator prevents capsules from moving and touching each other during transport. It also improves the presentation of the product thanks to its honeycomb shape.
Interseparador
![](https://www.imasdsl.com/wp-content/uploads/2023/10/Interseparador.jpg)
It provides stability at the different heights of the case, protecting the capsules and providing stability to the plant.
![](https://www.imasdsl.com/wp-content/uploads/2023/10/Separador-Mallado.jpg)
COMPATIBLE WITH STAR MOSAIC
The mesh separator prevents capsules from moving and touching each other during transport. It also improves the presentation of the product thanks to its honeycomb shape.
![](https://www.imasdsl.com/wp-content/uploads/2023/10/Interseparador.jpg)
COMPATIBLE WITH STAR AND TWIST MOSAIC
It provides stability at the different heights of the case, protecting the capsules and providing stability to each plant.
Capsule case in 1-height packaging
![COMPOSICION_4_ALTURAS_NP_STAR](https://www.imasdsl.com/wp-content/uploads/2023/10/COMPOSICION_4_ALTURAS_NP_STAR-1.jpg)
Specifications
DIMENSIONS
TECHNICAL INFORMATION
Electrical installation
3P + N + TT
Phase voltage:
400 VAC
Minimum cable section
10 mm
Electrical power supply
15 kW
MECHANICAL INFORMATION
Dimensions (L x W x H)
5034 x 2686 x 2766 mm
Weight:
3800 kg
PNEUMATIC INFORMATION
Air consumption:
500 l/min.
Exhaust air pressure:
6 bar
Technical information
Electrical installation
3P + N + TT
Phase voltage:
400 VAC
Minimum cable section
10 mm
Electrical power supply:
15 kW
Mechanical Information
Dimensions (L x W x H)
5034 x 2686 x 2766 mm
Weight:
3800 kg
Pneumatic Information
Air consumption:
650 l/min.
Exhaust air pressure:
6 bar
NP-ONE STAR
200/250 cap/min case.
![](/wp-content/uploads/2023/10/Caja_Tipo-A_STAR-1.jpg)
![](/wp-content/uploads/2023/10/Caja_Tipo-B_STAR-1.jpg)
CASES
Type A
Type B
Type C
![](/wp-content/uploads/2023/10/Caja_Alturas_10_NP-3.jpg)
![](/wp-content/uploads/2023/10/Caja_Alturas_20_NP-2.jpg)
![](/wp-content/uploads/2023/10/Caja_Alturas_30_NP-2.jpg)
HEIGHT
Up to 4 heights
![](/wp-content/uploads/2023/10/Mosaico_STAR_2-2.jpg)
MOSAIC
Star (4x2+2)
Star (4x2+3)
![](/wp-content/uploads/2023/10/Honeycomb_STAR-2.jpg)
OPTIONAL
Honeycomb
Interlayer
NP ONE STAR
CASES
![](https://www.imasdsl.com/wp-content/uploads/2023/10/Caja_Tipo-A_STAR-1.jpg)
![](https://www.imasdsl.com/wp-content/uploads/2023/10/Caja_Tipo-B_STAR-1.jpg)
![](https://www.imasdsl.com/wp-content/uploads/2023/10/Caja_Tipo-C_STAR-1.jpg)
HEIGHTS
![](https://www.imasdsl.com/wp-content/uploads/2023/10/Caja_Alturas_10_NP-3.jpg)
![](https://www.imasdsl.com/wp-content/uploads/2023/10/Caja_Alturas_20_NP-2.jpg)
![](https://www.imasdsl.com/wp-content/uploads/2023/10/Caja_Alturas_30_NP-2.jpg)
![](https://www.imasdsl.com/wp-content/uploads/2023/10/Caja_Alturas_40_NP-2.jpg)
Up to 4 heights
MOSAIC
![](https://www.imasdsl.com/wp-content/uploads/2023/10/Mosaico_STAR_2-2.jpg)
Estrella (4x2+2)
![](https://www.imasdsl.com/wp-content/uploads/2023/10/Mosaico_STAR_3.jpg)
Estrella (4x2+3)
OPTIONALS
![](https://www.imasdsl.com/wp-content/uploads/2023/10/Honeycomb_STAR-2.jpg)
Honeycomb
![](https://www.imasdsl.com/wp-content/uploads/2023/10/Interlayer_STAR-1.jpg)
EInterlayer
