DG-ONE STAR
![DG ONE STAR](https://www.imasdsl.com/wp-content/uploads/2023/10/DG-ONE-STAR-1.jpg)
Cartoner with a rate of 200/250 capsules/minute.
Packagings up to 4 heights
Star Mosaic Presentation
Up to 4 heights
Star Mosaic
![DG ONE STAR](https://www.imasdsl.com/wp-content/uploads/2023/10/DG-ONE-STAR-1.jpg)
DG-ONE STAR
Our most versatile cartoner: it works with cases up to 4 heights, in star mosaic and a rate of 200/250 cap/min.
![ONE-2](https://www.imasdsl.com/wp-content/uploads/2023/10/ONE-2.png)
Type of capsules
![](/wp-content/uploads/2023/10/NP.jpg)
NESPRESSO
![](/wp-content/uploads/2023/10/TU-CAPSULA.jpg)
YOUR CAPSULE
Models
It contains the main capsule models on the market, adapting to specific formats and sizes.
![](/wp-content/uploads/2023/10/NP.jpg)
NESPRESSO
![](/wp-content/uploads/2023/10/TU-CAPSULA.jpg)
YOUR CAPSULE
![](/wp-content/uploads/2023/10/ALUMINIO.jpg)
ALUMINUM
![](/wp-content/uploads/2023/10/PLASTICO.jpg)
PLASTIC
![](/wp-content/uploads/2023/10/COMPOSTABLE.jpg)
COMPOSTABLE
Materials
A machine for three types of capsules. Boxes that seek maximum protection, resistance and product presentation.
![](/wp-content/uploads/2023/10/ALUMINIO.jpg)
ALUMINUM
![](/wp-content/uploads/2023/10/PLASTICO.jpg)
PLASTIC
![](/wp-content/uploads/2023/10/COMPOSTABLE.jpg)
COMPOSTABLE
Star Mosaic
Great protection and security for the capsule and coffee with an attractive and comfortable presentation.
![DG ONE STAR_SEPARADOR](https://www.imasdsl.com/wp-content/uploads/2023/10/DG-ONE-STAR_SEPARADOR.jpg)
CHARACTERISTICS
Cases
I+DELTA BOX DG-ONE STAR works with three types of iron-on cases according to the needs of protection, ease of closure and accessibility to the capsules.
![DG ONE STAR_Tipo A](https://www.imasdsl.com/wp-content/uploads/2023/10/DG-ONE-STAR_Tipo-A.jpg)
Reduces glue spots without compromising case integrity.
![DG ONE STAR_Tipo B](https://www.imasdsl.com/wp-content/uploads/2023/10/DG-ONE-STAR_Tipo-B.jpg)
An airtight design that guarantees maximum product safety.
![DG ONE STAR_Tipo C](https://www.imasdsl.com/wp-content/uploads/2023/10/DG-ONE-STAR_Tipo-C-1.jpg)
An agile opening and closing system with a premium design.
Optional
Choose the optional ones that best suit your needs:
Mesh separator
![](https://www.imasdsl.com/wp-content/uploads/2023/10/DG-ONE-STAR_SEPARADOR-1.jpg)
The mesh separator prevents capsules from moving and touching each other during transport. It also improves the presentation of the product thanks to its honeycomb shape.
Interseparator
![](https://www.imasdsl.com/wp-content/uploads/2023/10/DG-INTERLAYER.jpg)
It provides stability at the different heights of the case, protecting the capsules and providing stability to the plant.
![](https://www.imasdsl.com/wp-content/uploads/2023/10/DG-ONE-STAR_SEPARADOR-1.jpg)
COMPATIBLE WITH STAR MOSAIC
The mesh separator prevents capsules from moving and touching each other during transport. It also improves the presentation of the product thanks to its honeycomb shape.
![](https://www.imasdsl.com/wp-content/uploads/2023/10/DG-INTERLAYER.jpg)
COMPATIBLE WITH STAR AND TWIST MOSAIC
It provides stability at the different heights of the case, protecting the capsules and providing stability to each plant.
Capsule case in 1-height packaging
I+DELTA BOX NP LITE STAR is compatible with 1-height cases with capacity from 10 to 44 capsules per case.
![DG ONE STAR_COMPOSICION](https://www.imasdsl.com/wp-content/uploads/2023/10/DG-ONE-STAR_COMPOSICION.jpg)
Specifications
DIMENSIONS
TECHNICAL INFORMATION
Electrical installation
3P + N + TT
Phase voltage:
400 VAC
Minimum cable section:
10mm
Power supply:
15 kW
MECHANICAL INFORMATION
Dimensions (L x W x H)
5323 x 2766 x 2868 mm
Weight:
4150 kg
PNEUMATIC INFORMATION
Air consumption:
650 l/min
Exhaust air pressure:
6 bar
technical information
Electrical installation
3P + N + TT
Phase voltage:
400 VAC
Minimum cable section
10 mm
Electrical power supply:
15 kW
mechanical information
Dimensions (L x W x H)
5323 x 2766 x 2868 mm
Weight:
4150kg
pneumatic information
Air consumption:
650 l/min
Exhaust air pressure:
6 bar
DG-ONE STAR
200/250 cap/min case.
![](/wp-content/uploads/2023/10/DG-ONE-STAR_Tipo-A-1.jpg)
![](/wp-content/uploads/2023/10/DG-ONE-STAR_Tipo-B-1.jpg)
CASES
Type A
Type B
Type C
![DZ-4-ALTURAS-TIPO-B](https://www.imasdsl.com/wp-content/uploads/2023/10/DZ-4-ALTURAS-TIPO-B-1.jpg)
HEIGHT
Up to 4 heights
![](/wp-content/uploads/2023/10/DG_MOSAICO_star-3.jpg)
MOSAIC
Star (3x2+2)
Star (2x2+1)
![](/wp-content/uploads/2023/10/DG_honeycomb.jpg)
OPTIONAL
Honeycomb
Interlayer
DG-ONE STAR
![](https://www.imasdsl.com/wp-content/uploads/2023/10/DG-ONE-STAR_Tipo-A-1.jpg)
![](https://www.imasdsl.com/wp-content/uploads/2023/10/DG-ONE-STAR_Tipo-B-1.jpg)
![](https://www.imasdsl.com/wp-content/uploads/2023/10/DG-ONE-STAR_Tipo-C-2.jpg)
![](https://www.imasdsl.com/wp-content/uploads/2023/10/DZ-4-ALTURAS-TIPO-B-1.jpg)
![](https://www.imasdsl.com/wp-content/uploads/2023/10/DG_MOSAICO_star-3.jpg)
![](https://www.imasdsl.com/wp-content/uploads/2023/10/DG_MOSAICO_star.jpg)
![](https://www.imasdsl.com/wp-content/uploads/2023/10/DG_honeycomb.jpg)
![](https://www.imasdsl.com/wp-content/uploads/2023/10/DG_interlayer.jpg)
